General information
Brand: Jaguar
Model: F-Pace
Generation: Facelift 2020
Modification (Engine): 3.0d (300 Hp) AWD Automatic
Start of production: 2020 year
End of production: -
Powertrain Architecture: Internal Combustion engine
Body type: SUV
Seats: 5
Doors: 5
Performance specs
Acceleration 0 - 100 km/h: 6.4 sec
Acceleration 0 - 62 mph: 6.4 sec
Maximum speed: 230 km/h / 142.92 mph
Emission standard: Euro 5
Weight-to-power ratio: 6.7 kg/Hp, 148.7 Hp/tonne
Weight-to-torque ratio: 3.1 kg/Nm, 322.3 Nm/tonne
Engine specs
Power: 300 Hp @ 4000 rpm.
Power per litre: 100.1 Hp/l
Torque: 650 Nm @ 1500-2500 rpm.
Engine location: Front, Longitudinal
Engine Model/Code: -
Engine displacement: 2996 cm3 / 182.83 cu. in.
Number of cylinders: 6
Position of cylinders: Inline
Cylinder Bore: 83.01 mm / 3.27 in.
Piston Stroke: 92.3 mm / 3.63 in.
Compression ration: 15.5
Number of valves per cylinder: 4
Fuel System: Diesel Commonrail
Engine aspiration: Turbocharger
Valvetrain: -
Engine oil capacity: -
Coolant: -
Engine systems: Start & Stop System
Particulate filter
Space, Volume and weights
Kerb Weight: 2017 kg / 4446.72 lbs.
Max Weight: -
Max load: -Trunk (boot) space - minimum: 793 l
28 cu. ft.
Fuel tank capacity: 66 l
17.44 US gal
14.52 UK gal
AdBlue tank: 17 l
4.49 US gal | 3.74 UK gal
Permitted trailer load with brakes (12%): 2400 kg / 5291.09 lbs.
Permitted trailer load without brakes: 750 kg / 1653.47 lbs.
Dimensions
Length: 4747 mm / 186.89 in.
Width: -
Width with mirrors folded: 2071 mm / 81.54 in.
Width including mirrors: 2175 mm / 85.63 in.
Height: 1664 mm / 65.51 in.
Wheelbase: 2874 mm / 113.15 in.
Front track: 1640 mm / 64.57 in.
Rear (Back) track: 1656 mm / 65.2 in.
Front overhang: 845 mm / 33.27 in.
Rear overhang: 1028 mm / 40.47 in.
Minimum turning circle (turning diameter): 11.93 m / 39.14 ft.
Approach angle: 22.5°
Departure angle: 22.9°
Ramp angle: 19.0°
Wading depth: 500 mm / 19.69 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture: The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary.
Drive wheel: All wheel drive (4x4)
Number of Gears (automatic transmission): 8 ZF
Front suspension: Double wishbone
Rear suspension: Multi-link independent
Front brakes: Ventilated discs, 370 mm
Rear brakes: Ventilated discs, 325 mm
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Electric Steering
Tires size: -
Wheel rims size: -
