General information
Brand: Cadillac
Model: ATS
Generation: Coupe 2016
Modification (Engine): V 3.6 V6 (471 Hp) Automatic
Start of production: 2016 year
End of production: -
Powertrain Architecture: Internal Combustion engine
Body type: Coupe
Seats: 4
Doors: 2
Performance specs
19.22 UK mpg
6.8 km/l
28.82 UK mpg
10.2 km/l
22.78 UK mpg
8.06 km/l
Acceleration 0 - 100 km/h: 4.2 sec
Acceleration 0 - 62 mph: 4.2 sec
Maximum speed: 298 km/h / 185.17 mph
Emission standard: -
Weight-to-power ratio: 3.7 kg/Hp, 273 Hp/tonne
Weight-to-torque ratio: 2.9 kg/Nm, 349.6 Nm/tonne
Engine specs
Power: 471 Hp @ 5850 rpm.
Power per litre: 132.2 Hp/l
Torque: 603 Nm @ 3500 rpm.
Engine location: Front, Longitudinal
Engine Model/Code: LF4
Engine displacement: 3564 cm3 / 217.49 cu. in.
Number of cylinders: 6
Position of cylinders: V-engine
Cylinder Bore: 94 mm / 3.7 in.
Piston Stroke: 85.6 mm / 3.37 in.
Compression ration: 10.2
Number of valves per cylinder: 4
Fuel System: Direct injection
Engine aspiration: Twin-Turbo, Intercooler
Valvetrain: DOHC-VVT
Engine oil capacity: 6.6 l
6.97 US qt
5.81 UK qt
Coolant: 10.2 l
10.78 US qt
8.97 UK qt
Engine systems: -
Space, Volume and weights
Kerb Weight: 1725 kg / 3802.97 lbs.
Max Weight: -
Trunk (boot) space - minimum: 295 l
10.42 cu. ft.
Fuel tank capacity: 60.5 l
15.98 US gal
13.31 UK gal
Permitted trailer load with brakes (12%): -
Permitted trailer load without brakes: -
Dimensions
Length: 4691 mm / 184.69 in.
Width: 1841 mm / 72.48 in.
Width with mirrors folded: -
Width including mirrors: -
Height: 1384 mm / 54.49 in.
Wheelbase: 2775 mm / 109.25 in.
Front track: 1538 mm / 60.55 in.
Rear (Back) track: 1559 mm / 61.38 in.
Front overhang: -.
Rear overhang: -
Minimum turning circle (turning diameter): 11.7 m / 38.39 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture: The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel: Rear wheel drive
Number of Gears (automatic transmission): 8 Hydra-Matic
Front suspension: Independent, Spring McPherson, with stabilizer
Rear suspension: Multi-link independent
Front brakes: Ventilated discs
Rear brakes: Ventilated discs
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Electric Steering
Tires size: 255/35 R18; 275/35 R18
Wheel rims size: 9J x 18; 9.5J x 18
